Pipe Fusion Machine V200 CNC

Pipe Fusion Machine V200 CNC
Pipe Fusion Machine V200 CNCPipe Fusion Machine V200 CNCPipe Fusion Machine V200 CNCPipe Fusion Machine V200 CNCPipe Fusion Machine V200 CNC
Welding Range in mm63-200mm
Welding Range in inch2" - 6" IPS
Power Supply220V±10%, 50/60HZ
Standard AppliedISO21307, DVS2207 etc
CertificateCE, ISO9001
Tempreture RangeMAX. 320 ºC
Working Pressure Range0 - 80 BAR
Contact Now
Detail Information
Detail Information
Pipe Fusion Machine V200 CNC Introduction
The RIYANG V200 CNC automatic hydraulic butt welding machine is specially designed for joining PE, PP, PPR, and PVDF pipes and molded fittings. It uses high-quality, durable components to ensure long service life, resulting in reliable performance with minimal maintenance. Its user-friendly design makes operation smooth and efficient, ideal for various industrial applications.

Pipe Fusion Machine V200 CNC Features

Advanced Heating & Safety Trimmer

· Stainless steel protective casing prevents corrosion and enhances durability in demanding work conditions.

· The new-generation facing tool offers smoother, more stable torque output, with longer service life — setting a benchmark in the industry.

· The heating plate features a high-performance Teflon coating, enhancing non-stick properties between the plate and pipe surface.

Strong & Leak-Proof Frame

· Shafts are precision-machined and feature multi-stage surface treatment and enhanced plating, improving strength and long-term structural stability.

· Key hydraulic components, including seals and quick couplings, are sourced from renowned international brands to ensure long-lasting performance.

· The upgraded clamping system uses reinforced aluminum alloy for greater hardness and resistance to deformation.

Smart & Reliable Control

· Built-in operator management system allows different users to create accounts, enabling traceability of individual welding tasks.

· The control box is ergonomically designed, with an adjustable sunshade to reduce screen glare under direct sunlight.

· Supports remote diagnostics and firmware upgrades, allowing real-time technical support from the manufacturer and minimizing downtime..

Pipe Fusion Machine V200 CNC Technical Parameters

Product model
V200 CNC
Welding Range O.D.
63-200mm
Welding Range Inch
2" - 6" IPS
Heater Power
1.5 KW
Trimmer Power
0.75 KW
Pump Power
0.75 KW
Working Pressure Range
0 - 80 BAR
Power supply
220V±10%, 50/60HZ
Gross Weight
156 KGS
Packing Material
Plywood Box
Max. HeatingTemperature
320°C
* Parameters are measured under standard operating conditions and may vary in actual use.
* If you notice any issues or need help adjusting the parameters, feel free to contact us.

File Downloads

For more product related parameter files, please contact us.
Detail Information

Want a Custom Configuration for Your Production Line?

Contact us to learn more about how Pipe Butt Fusion Machine V200 CNC can simplify your welding process and ensure high-quality results.
